| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,729 pcs
|
1729 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Diode Configuration | |
| Mounting Type | |
| Operating Temperature | |
| Reverse Recovery Time (trr) | |
| Speed | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Voltage |
The CDSH3-222N-G is a general-purpose fast recovery diode array manufactured by Comchip Technology. It is configured as one pair of common cathode diodes, providing two diodes in a single SOT-523 surface mount package. The device is rated for a maximum reverse voltage of 80V and a forward current of 300mA, with a forward voltage of 1.2V at 100mA test current.
This diode array offers a fast reverse recovery time of 4ns, making it suitable for high-speed switching applications where low recovery losses are important. The reverse leakage current is specified at 100nA at 70V reverse voltage, indicating low leakage for efficient operation. The device operates at junction temperatures up to 150°C, supporting use in thermally demanding environments.
The SOT-523 package is a compact, surface mount form factor ideal for space-constrained PCB designs. The common cathode configuration simplifies circuit layout in applications requiring two diodes with a shared cathode connection. This component is categorized under Diodes - Rectifiers - Arrays, suitable for general rectification and switching functions in various electronic circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.38 | $0.38 |
| 10+ | $0.26 | $0.26 |
| 100+ | $0.17 | $0.17 |
| 500+ | $0.11 | $0.11 |
| 1,000+ | $0.09 | $0.09 |
| 3,000+ | $0.06 | $0.06 |
| 6,000+ | $0.05 | $0.05 |
| 9,000+ | $0.05 | $0.05 |
| 24,000+ | $0.04 | $0.04 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum reverse voltage (VRRM) is 80V.
The forward current (IF) is rated at 300mA.
The forward voltage is 1.2V at a test current of 100mA.
The reverse recovery time (trr) is 4ns.
It is available in a SOT-523 surface mount package.
It is configured as one pair of common cathode diodes.
The maximum operating junction temperature is 150°C.
