| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
95 pcs
|
95 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The CDR-04-TR is a 4 position single row right angle male pin header from Adam Technologies Inc. It features a 2.54mm (0.100") pitch and through hole solder termination, making it suitable for standard board-to-cable/wire connections. The unshrouded design with latch holder fastening provides secure mating, while the polarizing key ensures correct orientation.
The header is rated for 3A current and 250VAC voltage, with an operating temperature range of -40°C to 105°C. Contacts are made of brass with tin plating, and the insulator is black glass-filled PBT with a UL94 V-0 flammability rating. This component is RoHS3 and REACH compliant, with MSL 1 unlimited.
4 positions, all loaded.
2.54mm (0.100").
3A.
250VAC.
Through hole, right angle.
-40°C to 105°C.
Brass contacts with tin plating.
