CDP68HC68T1M2 The Renesas CDP68HC68T1M2 is a Clock/Calendar IC with an SPI interface, designed for surface mount applications. It operates within a voltage range of 2.2V to 6V.
Mfr Part #:

CDP68HC68T1M2

Available from 1 distributors
Mfr Name: Renesas
Renesas
The Renesas CDP68HC68T1M2 is a Clock/Calendar IC with an SPI interface, designed for surface mount applications. It operates within a voltage range of 2.2V to 6V.
✓ Total Stock: 3,500 pcs

CDP68HC68T1M2 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
3,500 pcs
On Request
3500 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CDP68HC68T1M2 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Date Format
Features
Interface
Memory Size
Mounting Type
Operating Temperature
Operating Voltage
Supplier Device Package
Time Format
Type
Voltage
View Similar Products (0)

CDP68HC68T1M2 Description

Short technical summary and product information.

This Renesas CDP68HC68T1M2 is an integrated circuit functioning as a Clock/Calendar with an SPI interface. It is housed in a 16-SOIC package suitable for surface mounting.



The device supports a wide operating voltage range from 2.2V to 6V, with a timekeeping current consumption of 20µA to 500µA at 5V. Key features include an alarm function, leap year calculation, square wave output, and a watchdog timer. The time format can be displayed in HH:MM:SS (12/24 hr) and the date format is YY-MM-DD-dd. The memory size is 32B.



Operating within a temperature range of -40°C to 85°C, this component is designed for reliable performance in various environmental conditions. Its RoHS3 compliant status indicates adherence to certain environmental regulations. The 16-SOIC package has a width of 7.50mm (0.295").



This real-time clock IC is suitable for applications requiring accurate timekeeping and calendar functions, integrated into systems via its SPI interface.

CDP68HC68T1M2 Quick Information

Product Type: Real Time Clock IC
Canonical Name: CDP68HC68T1M2 Real Time Clock IC
Subcategory: Real Time Clocks

CDP68HC68T1M2 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

CDP68HC68T1M2 Features

  • Clock/Calendar IC with SPI interface.
  • Operates from 2.2V to 6V supply voltage.
  • Features alarm, leap year, and watchdog timer.
  • Surface mount 16-SOIC package.
  • Wide operating temperature range.

CDP68HC68T1M2 Applications

  • Accurate timekeeping in embedded systems.
  • Calendar functions for data logging.
  • System monitoring with watchdog timer.
  • Power-efficient timekeeping applications.

CDP68HC68T1M2 FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the CDP68HC68T1M2?

The operating voltage range is 2.2V to 6V.

What package type is the CDP68HC68T1M2 available in?

It is available in a 16-SOIC package.

What is the operating temperature range for this real-time clock IC?

The operating temperature range is -40°C to 85°C.

What is the RoHS status of the CDP68HC68T1M2?

The RoHS status is RoHS3 Compliant.
