| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
72,320 pcs
|
72320 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Differential | |
| Divider | |
| Frequency | |
| Input | |
| Input Type | |
| Mounting Type | |
| Number of Circuits | |
| Number of Outputs | |
| Operating Temperature | |
| Output | |
| Output Type | |
| PLL | |
| Quiescent Current | |
| Ratio | |
| Supplier Device Package | |
| Supply Voltage | |
| Type | |
| Voltage |
The CDCVF857DGG from Texas Instruments is a 2.5V Phase-Lock Loop DDR Clock Driver designed for high-performance clock distribution. It features 10 differential clock outputs and operates within a frequency range of 60 MHz to 220 MHz.
Key electrical specifications include low additive RMS jitter of 30 fs (typ), output skew of 75 ps, and low cycle-to-cycle jitter of ±35 ps. The device operates from a core supply voltage of 2.5V and an output supply voltage of 1.7V, with a wide input voltage range of 2.3V to 2.7V. It consumes less than 100 µA of quiescent current.
This clock driver meets or exceeds JEDEC standards JESD82-1 for DDR I-200/266/333 and the proposed JESD82-1A for DDR I-400. It is available in a 48-TSSOP package, suitable for surface mount applications.
The CDCVF857DGG is ideal for applications such as DDR memory modules (DDR400/333/266/200) and zero-delay fan-out buffer requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.26 | $7.26 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The CDCVF857DGG operates from a 2.3V to 2.7V supply voltage.
The CDCVF857DGG is available in a 48-TSSOP package.
The operating temperature range for the CDCVF857DGG is -40°C to 85°C.
The CDCVF857DGG is RoHS3 Compliant.
