CDC7005ZVAR The Texas Instruments CDC7005ZVAR is a high-performance clock synchronizer and jitter cleaner. It synchronizes a VCXO frequency to a reference clock with low phase noise and skew.
Mfr Part #:

CDC7005ZVAR

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments CDC7005ZVAR is a high-performance clock synchronizer and jitter cleaner. It synchronizes a VCXO frequency to a reference clock with low phase noise and skew.
✓ Total Stock: 14,332 pcs
$ Price Range: $12.67

CDC7005ZVAR Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Unit Electronics Co.,Limited ✓
Non-Authorised Inventory information
9,206 pcs
On Request
9206 pcs On Request 1 On Request On Request On Request On Request On Request
Romaks Technologies ✓
Non-Authorised Inventory information
3,117 pcs
On Request
3117 pcs On Request 1 On Request On Request On Request On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
2,009 pcs
On Request
2009 pcs On Request 1 On Request On Request 24+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CDC7005ZVAR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Differential
Divider
Features
Frequency
Input
Input Type
Lead Spacing
Lead Style
Mounting Type
Number of Circuits
Number of Outputs
Operating Temperature
Output
Output Type
PLL
Ratio
Supplier Device Package
Type
Voltage
View Similar Products (0)

CDC7005ZVAR Description

Short technical summary and product information.

The Texas Instruments CDC7005ZVAR is a high-performance, low-phase noise, and low-skew clock synchronizer and jitter cleaner. This device synchronizes the voltage-controlled crystal oscillator (VCXO) frequency to the reference clock. It supports frequencies up to 800 MHz on the VCXO input and provides five differential LVPECL outputs.



Key features include an integrated low-noise op-amp for an external low-pass filter, efficient jitter screening, and programmable delay for phase adjustments. The device operates with a core and output supply voltage of 3.3V and has an operating temperature range of -40°C to 85°C. It is available in a 64-BGA (8x8) or 48-pin QFN package, suitable for surface mounting.



The CDC7005ZVAR offers flexibility with programmable predividers M and N, allowing for adjustable frequency ratios. The PLL loop bandwidth and damping factor can be tuned by selecting external VCXO and loop filter components to meet specific system requirements. Each output frequency is selectable, and all outputs are synchronized.

CDC7005ZVAR Quick Information

Product Type: Clock Synchronizer and Jitter Cleaner
Series: CDC7005
Canonical Name: CDC7005 High Performance, Low Phase Noise, Low Skew Clock Synchronizer and Jitter Cleaner
Subcategory: Jitter Cleaner

CDC7005ZVAR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

CDC7005ZVAR Estimated Pricing

Qty Low High
1+ $12.67 $12.67

Estimated market price range - modelled values for guidance only, not live distributor offers.

CDC7005ZVAR Features

  • High performance clock synchronizer and jitter cleaner.
  • Synchronizes VCXO to reference clock up to 800 MHz.
  • Provides five differential LVPECL outputs.
  • Low phase noise and low skew characteristics.
  • Operates at 3.3V with industrial temperature range.

CDC7005ZVAR Applications

  • Ideal for high-speed clock distribution.
  • Used in systems requiring precise timing.
  • Suitable for telecommunications infrastructure.
  • Applicable in test and measurement equipment.

CDC7005ZVAR FAQs

7 frequently asked questions generated from this part’s specifications.
What type of component is the CDC7005ZVAR?

The CDC7005ZVAR is a Clock Synchronizer and Jitter Cleaner.

How many outputs does the CDC7005ZVAR have?

The CDC7005ZVAR has 5 outputs.

What is the output type of the CDC7005ZVAR?

The output type is LVPECL.

What is the maximum output frequency of the CDC7005ZVAR?

The maximum output frequency is 800MHz.

What is the operating temperature range for the CDC7005ZVAR?

The operating temperature range is -40°C to 85°C.

What are the key features of the CDC7005ZVAR?

Key features include an op-amp for active loop filter and programmable delay.

What is the package type for the CDC7005ZVAR?

The package is 64-BGA (8x8) or 64-LFBGA.
