| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Features | |
| Mounting Type | |
| Number of Inputs | |
| Power Dissipation | |
| Technology |
The RCA CD54HC00F is a high-performance CMOS Quad 2-Input NAND Gate. It belongs to the HC/UH SERIES and is designed for reliable operation.
Key electrical characteristics include a nominal supply voltage of 5V, with a minimum operating voltage of 2V and a maximum of 6V. The propagation delay is a maximum of 135ns. The device has a maximum power dissipation of 500mW and offers a noise rejection of up to 1.2V.
This logic IC operates within a temperature range of -55°C to 125°C. It features 4 circuits per package, each with 2 inputs, and utilizes Totem-Pole output features. The package is CDIP14 with a terminal pitch of 2.54 mm, designed for through-hole mounting.
The CD54HC00F is suitable for various digital logic applications requiring NAND functionality.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal supply voltage for the CD54HC00F is 5V.
The CD54HC00F operates from -55°C to 125°C.
The maximum propagation delay for the CD54HC00F is 135ns.
The CD54HC00F is supplied in a CDIP14 package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
