| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8,309 pcs
|
8309 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,202 pcs
|
1202 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
250 pcs
|
250 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance @ Vr, F | |
| Current | |
| Current - Average Rectified (Io) | |
| Forward Voltage (Vf) (Max) @ If | |
| Mounting Type | |
| Operating Temperature | |
| Package / Case | |
| Reverse Recovery Time (trr) | |
| Speed | |
| Supplier Device Package | |
| Technology | |
| Voltage | |
| Voltage - DC Reverse (Vr) (Max) |
The Bourns CD1206-S01575 is a general purpose rectifier diode designed for low-power applications. It features a maximum reverse voltage rating of 100V and an average rectified current of 150mA. The forward voltage is specified at 1V when tested with a forward current of 50mA. The diode exhibits a fast reverse recovery time of 4ns, making it suitable for high-speed switching circuits. It has a typical capacitance of 3pF at 0V reverse bias and 100MHz frequency.
The diode utilizes standard silicon technology and is rated for operation over a temperature range of -55°C to 125°C. It is housed in a surface mount 1206 (3216 Metric) package, which is suitable for automated assembly processes. The supplier device package is also designated as 1206.
This component is classified as a small signal diode with a speed rating of Small Signal =< 200mA (Io), Any Speed, indicating it is optimized for low current rectification. The part is commonly used in general purpose rectification, signal demodulation, and protection circuits. RoHS compliance is indicated but not verified.
The maximum reverse voltage (Vr) is 100V.
The maximum average rectified current (Io) is 150mA.
The forward voltage (Vf) is 1V maximum at a forward current of 50mA.
The reverse recovery time (trr) is 4ns.
It is available in a 1206 (3216 Metric) surface mount package.
The operating temperature range is -55°C to 125°C.
The typical capacitance is 3pF at 0V reverse bias and 100MHz.
