CCR05CG680JM 68 pF radial ceramic capacitor with C0G dielectric, ±5% tolerance, and 50V rating. Through-hole mounting with radial leads.
Mfr Part #:

CCR05CG680JM

Available from 1 distributors
Mfr Name: Kyocera AVX
Kyocera AVX
68 pF radial ceramic capacitor with C0G dielectric, ±5% tolerance, and 50V rating. Through-hole mounting with radial leads.
✓ Total Stock: 96 pcs

CCR05CG680JM Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
96 pcs
On Request
96 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CCR05CG680JM Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Capacitance
Lead Spacing
Lead Style
Mounting Type
Operating Temperature Range
Package / Case
Temperature Coefficient
Termination Style
Tolerance
Voltage Rating
View Similar Products (0)

CCR05CG680JM Description

Short technical summary and product information.

The CCR05CG680JM is a 68 pF ceramic capacitor from Kyocera AVX, featuring C0G (NP0) dielectric. It offers a capacitance tolerance of ±5% and a rated voltage of 50V. The C0G dielectric provides a stable temperature coefficient of ±30 ppm/°C over an operating temperature range of -55°C to +125°C. This component is designed for through-hole mounting with a radial lead style and standard lead spacing of 0.200" (5.08mm). It is suitable for general-purpose applications requiring stable capacitance over temperature, such as bypass, coupling, and timing circuits. The capacitor is RoHS3 compliant, REACH unaffected, and has an MSL of 1, indicating no moisture sensitivity.

CCR05CG680JM Quick Information

Product Type: Ceramic Capacitor
Series: CCR05
Canonical Name: 68 pF, ±5%, 50V, C0G, Radial Ceramic Capacitor
Subcategory: Radial Ceramic Capacitor

CCR05CG680JM Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

CCR05CG680JM Features

  • 68 pF capacitance with ±5% tolerance.
  • C0G dielectric for stable temperature coefficient.
  • Rated for 50V DC operation.
  • Through-hole radial lead mounting.
  • RoHS3 compliant and MSL 1.

CCR05CG680JM Applications

  • Ideal for bypass and decoupling circuits.
  • Used in timing and oscillator circuits.
  • Suitable for high-frequency filtering applications.
  • General purpose coupling and DC blocking.

CCR05CG680JM FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance of the CCR05CG680JM?

68 pF.

What is the tolerance of the capacitor?

±5%.

What is the voltage rating of the CCR05CG680JM?

50 V.

What is the temperature coefficient?

±30 ppm/°C.

What is the package style of this capacitor?

Radial leaded through-hole.

What is the operating temperature range?

-55°C to +125°C.

Is the CCR05CG680JM RoHS compliant?

Yes, it is RoHS3 compliant.
