| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
549 pcs
|
549 pcs | On Request | 1 | On Request | On Request | 23+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Antenna Type | |
| CPU | |
| Cryptographic accelerators | |
| Current | |
| Data Rate | |
| Edge AI Enabled | |
| Features | |
| Frequency | |
| Memory Size | |
| Modulation | |
| Mounting Type | |
| Operating System | |
| Operating Temperature | |
| Power | |
| Protocol | |
| Protocols | |
| RF Family | |
| Security | |
| Sensitivity | |
| Serial Interfaces | |
| Tape & Reel | |
| Throughput | |
| Type | |
| Utilized IC | |
| Voltage |
The Texas Instruments CC3235MODSM2MOBR is a highly integrated wireless MCU module designed for Wi-Fi connectivity. It features an Arm Cortex-M4 processor running at 80MHz, providing ample processing power for embedded applications. The module supports dual-band Wi-Fi (2.4 GHz and 5 GHz) with 802.11a/b/g/n protocols, offering flexible wireless communication.
With 256kB of RAM and optional 1MB of executable flash, the CC3235MODSM2MOBR is suitable for a wide range of IoT and embedded systems. It includes robust security features such as device attestation, secure boot, and secure communication, along with cryptographic accelerators for enhanced data protection. The module operates over an industrial temperature range of -40°C to 85°C, making it suitable for demanding environments.
Designed for easy integration, the CC3235MODSM2MOBR utilizes a 63-SMD Module package with a surface mount type. It offers various serial interfaces including I2C, I2S, SPI, and UART, facilitating connection to host systems and peripherals. The integrated antenna simplifies design and reduces board space requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $12.84 | $12.84 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The CC3235MODSM2MOBR uses an Arm Cortex-M4 processor core.
The CC3235MODSM2MOBR has 256kB of RAM and optional 1MB of executable flash.
The operating voltage range is 2.3V to 3.6V.
The operating temperature range is -40°C to 85°C.
It supports Wi-Fi 2.4 GHz and Wi-Fi 5 GHz protocols, including 802.11a/b/g/n.
Security features include device attestation & anti-counterfeit, FIPS 140-2 Level 1, secure boot, secure communication, secure firmware & software update, secure storage, and software IP protection.
Available serial interfaces include I2C, I2S, SPI, and UART.
