The OptiFuse CBW28-15A is a thermal circuit breaker designed for reliable overcurrent protection in electrical systems. It features a 1.5A current rating and is rated for up to 250 VAC and 32 VDC.
This circuit breaker utilizes thermal trip technology for long-term overcurrent protection and magnetic protection for short-circuit conditions. It has a breaking capacity of 1000A at 250 VAC and 200A at 32 VDC. The device includes a push-to-reset actuator for easy operation after a trip event.
Designed for convenient installation, the CBW28-15A features a snap-in front panel mount and 0.250” quick connect terminals. It is suitable for panel thicknesses ranging from 0.8 to 2.1mm. The circuit breaker is compliant with CSA and cULus agency standards.
Key specifications include a 1.5A current rating, 250VAC/32VDC voltage rating, and a 1000A interrupt capacity at 250VAC. The terminals are nickel-plated brass for durability. This component is intended for occasional overcurrent protection.
The datasheet lists 15 A, and the existing database lists 1.5 A.
The CBW28-15A is rated for 250 VAC and 32 VDC.
The interrupting capacity is 1000 A at 250 VAC, 50/60 Hz and 200 A at 32 VDC.
The CBW28-15A is supplied in bulk packaging.
It is a thermal circuit breaker with push-to-reset actuation.
The CBW28-15A is a single-pole circuit breaker.
For the 15 A rating, it may trip between 101% and 134% of rated current and must trip at 135% of rated current within one hour.
