| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
210 pcs
|
210 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Base Resonator | |
| Frequency | |
| Frequency Stability | |
| Function | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| Operating Voltage | |
| Output | |
| SVHC Present | |
| Tape & Reel | |
| Type |
The CB3LV-3C-50M0000-T from CTS-Frequency Controls is a standard XO (Crystal Oscillator) designed for electronic circuits requiring a stable frequency source. This component operates at a frequency of 4 MHz with a frequency stability of ±50 ppm, ensuring reliable performance.
It is designed to run on a 3.3V supply voltage and consumes a maximum of 12mA during operation, with a low disable current of 10µA. The output signal is compatible with HCMOS and TTL logic levels. The oscillator includes an enable/disable function for control.
This oscillator is housed in a compact 4-SMD, No Lead package, measuring 7.00mm x 5.00mm with a maximum seated height of 1.80mm. It is designed for surface mounting and is supplied on tape and reel, making it suitable for automated assembly processes. The operating temperature range is from -20°C to 70°C.
Key specifications include a base resonator type of Crystal, making it a robust choice for various timing applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.50 | $0.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating frequency is 4 MHz.
The frequency stability is ±50 ppm.
The required supply voltage is 3.3V.
It provides HCMOS and TTL compatible output.
The dimensions are 7.00mm x 5.00mm.
The operating temperature range is -20°C to 70°C.
Yes, it is RoHS3 Compliant.
