CAT16-220J4LF The Bourns CAT16-220J4LF is a resistor network array featuring 4 isolated resistors with a resistance of 22 Ohms and a tolerance of ±5%. It is designed for surface mounting in a 1206 package.
Mfr Part #:

CAT16-220J4LF

Available from 3 distributors
Mfr Name: Bourns
Bourns
The Bourns CAT16-220J4LF is a resistor network array featuring 4 isolated resistors with a resistance of 22 Ohms and a tolerance of ±5%. It is designed for surface mounting in a 1206 package.
✓ Total Stock: 96,381 pcs
$ Price Range: $0.05

CAT16-220J4LF Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Risen Electronics ✓
Non-Authorised Inventory information
90,000 pcs
On Request
90000 pcs On Request 1 On Request On Request On Request On Request 2026-02-16 21:33:16
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
3,222 pcs
On Request
3222 pcs On Request 1 On Request On Request On Request On Request On Request
Braun Electronic Components ✓
Non-Authorised Inventory information
3,159 pcs
On Request
3159 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CAT16-220J4LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Circuit Type
Height
Length
Mounting Type
Number of Elements
Number of Pins
Number of Resistors
Operating Temperature
Power Per Element
Resistance (Ohms)
Resistance Tolerance
Supplier Device Package
Temperature Coefficient
Tolerance
Width
View Similar Products (0)

CAT16-220J4LF Description

Short technical summary and product information.

This Bourns CAT16-220J4LF is a resistor network array from the CAT16 series. It comprises 4 isolated resistors, each with a resistance value of 22 Ohms and a tolerance of ±5%. The array is designed for surface mount applications and comes in a 1206 package.



The operating temperature range for this component is -55°C to 125°C, with a temperature coefficient of ±200ppm/°C. Each resistor element has a power rating of 62.5mW, and the total package power rating is 0.250W at 70°C. The circuit type is isolated.



Key specifications include a maximum working voltage of 50V and a maximum overload voltage of 100V. The component is RoHS3 compliant and has an MSL rating of 1.



This resistor network array is suitable for various electronic designs requiring multiple discrete resistors in a compact, surface-mountable form factor.

CAT16-220J4LF Quick Information

Product Type: Resistor Network Array
Series: CAT16
Canonical Name: Bourns CAT16-220J4LF Resistor Network Array
Subcategory: Array

CAT16-220J4LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

CAT16-220J4LF Estimated Pricing

Qty Low High
1+ $0.05 $0.05

Estimated market price range - modelled values for guidance only, not live distributor offers.

CAT16-220J4LF Features

  • Features 4 isolated resistor elements.
  • Offers 22 Ohms resistance with ±5% tolerance.
  • Rated for 62.5mW power per element.
  • Operates across -55°C to 125°C range.
  • Surface mountable in a 1206 package.

CAT16-220J4LF Applications

  • Suitable for general purpose circuit applications.
  • Used in compact electronic device designs.
  • Ideal for applications needing multiple resistors.
  • Provides reliable resistance in varying temperatures.

CAT16-220J4LF FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the Bourns CAT16-220J4LF resistor network?

The Bourns CAT16-220J4LF resistor network has a resistance value of 22 Ohms.

What is the tolerance for the resistors in the CAT16-220J4LF array?

The tolerance for the resistors in the CAT16-220J4LF array is ±5%.

How many resistors are in the Bourns CAT16-220J4LF resistor network?

The Bourns CAT16-220J4LF resistor network contains 4 isolated resistors.

What is the operating temperature range for the CAT16-220J4LF resistor array?

The operating temperature range for the CAT16-220J4LF resistor array is -55°C to 125°C.

What type of package is the Bourns CAT16-220J4LF resistor network in?

The Bourns CAT16-220J4LF resistor network is in a 1206 package.

What is the power rating per element for the CAT16-220J4LF resistor array?

The power rating per element for the CAT16-220J4LF resistor array is 62.5mW.
