| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature Range | |
| Operation | |
| Voltage | |
| Voltage Rating | |
| Weight | |
| Width |
The American Electrical Inc. C5A2P-GFI is a DIN rail mounted Ground Fault Interrupter Circuit Breaker with a 5A current rating and a 240V voltage rating. This 1-pole breaker utilizes a magnetic/hydraulic operation, ensuring performance unaffected by ambient temperature.
It is recognized under UL 1077 and UL 1053, and is CE approved. The breaker features a trip curve of 2 and operates within a temperature range of -40°C to +60°C. Its sensitivity is rated at 30mA for CE and 22mA for UL standards. The compact design measures 26mm in width.
GFCI circuit breakers provide advanced protection by instantly cutting power when a ground fault is detected, helping to prevent electric shocks and reduce fire risk. They monitor current flow between hot and neutral wires, tripping the circuit if even a small imbalance is detected.
The current rating is 5A.
The voltage rating is 240V.
It has 1 pole.
It is designed for DIN rail mounting.
It is a Ground Fault Interrupter circuit breaker.
It is approved by CE, UL1053, and UL1077.
The operating temperature range is -40°C to +60°C.
