Mfr Part #:

C5A1P-489

The American Electrical Inc. C5A1P-489 is a single-pole, magnetic-hydraulic circuit breaker rated for 5A and 240V. It features DIN rail mounting for easy installation.

Stock on Request

C5A1P-489 Description

Short technical summary and product information.

This American Electrical Inc. C5A1P-489 circuit breaker is designed for reliable overcurrent protection in AC circuits. It features a magnetic-hydraulic trip mechanism for consistent performance and a 100% rating capability.

With a current rating of 5A and a maximum voltage rating of 240V, this single-pole breaker is suitable for various industrial and commercial applications. Its compact 13 mm width and DIN rail mounting design facilitate efficient panel space utilization and quick installation.

The C5A1P-489 is UL489 and CE certified, ensuring compliance with relevant safety standards. It operates within a temperature range of -40°C to +60°C, making it robust for demanding environments.

C5A1P-489 Quick Information

Product Type: Circuit Breaker

Canonical Name: American Electrical Inc. C5A1P-489 Circuit Breaker

Subcategory: AC Circuit Breakers

C5A1P-489 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

C5A1P-489 Features

Single-pole magnetic-hydraulic circuit breaker.
Rated for 5A current and 240V AC.
Compact 13mm width for DIN rail mounting.
UL489 and CE certified for safety.
Operates from -40°C to +60°C.

C5A1P-489 Applications

Provides overcurrent protection in AC circuits.
Suitable for industrial electrical installations.
Used in control panel assemblies.
General purpose power distribution.

C5A1P-489 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the voltage rating of the C5A1P-489 circuit breaker?

240VAC.

What is the mounting type of the C5A1P-489 circuit breaker?

DIN Rail.

What is the operating temperature range of the C5A1P-489 circuit breaker?

-40°C to +60°C.

How many poles does the C5A1P-489 circuit breaker have?

1 pole.

What is the current rating of the C5A1P-489 circuit breaker?

5A.

What type of breaker is the C5A1P-489?

Magnetic (Hydraulic Delay).

What is the actuator type of the C5A1P-489 circuit breaker?

Lever.

Category	Circuit Breakers
Manufacturer Name	American Electrical Inc.
Actuator Type	Lever
Approval Agency	CE, UL489, UR
Breaker Type	Magnetic (Hydraulic Delay)
Current Rating	5A
Current Rating (Amps)	5A
Height	65 mm
Length	97.2 mm
Mounting Type	DIN Rail
Number of Poles	1
Operating Temperature Range	-40°C to +60°C
SVHC Present	Not Present
Voltage Rating	240V
Weight	102 g
Width	13 mm
