C40A1P The American Electrical Inc. C40A1P is a single-pole, DIN rail mountable circuit breaker featuring magnetic-hydraulic technology. It offers a 40A current rating and a 480V AC voltage rating.
Mfr Part #:

C40A1P

Mfr Name: American Electrical Inc.
American Electrical Inc.
The American Electrical Inc. C40A1P is a single-pole, DIN rail mountable circuit breaker featuring magnetic-hydraulic technology. It offers a 40A current rating and a 480V AC voltage rating.
Stock on Request

C40A1P Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Type
Approval Agency
Breaker Type
Current Rating
Current Rating (Amps)
Industrial Grade
Mounting Type
Number of Poles
Operating Temperature Range
Voltage Rating
View Similar Products (0)

C40A1P Description

Short technical summary and product information.

This American Electrical Inc. C40A1P is a single-pole circuit breaker designed for DIN rail mounting. It utilizes hydraulic-magnetic technology for reliable operation and protection.



The breaker has a current rating of 40 Amps and a maximum operating voltage of 480 Volts AC. It is approved by CE and UL1077, ensuring compliance with industry standards.



Key technical data includes an interrupting capacity of 10,000A, an operating temperature range from -40°C to +60°C, and a dielectric strength of 1500V. The compact 13mm width makes it suitable for space-constrained applications.



This component is ideal for overcurrent protection in various industrial and commercial electrical systems where DIN rail mounting is specified.

C40A1P Quick Information

Product Type: Circuit Breaker
Canonical Name: American Electrical Inc. C40A1P DIN Rail Mounted Magnetic-Hydraulic Circuit Breaker
Subcategory: DIN Rail Mounted Circuit Breaker

C40A1P Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

C40A1P Features

  • Single pole DIN rail circuit breaker.
  • 40 Amp current rating.
  • 480 Volt AC maximum voltage.
  • Magnetic-hydraulic trip mechanism.
  • UL1077 and CE approved.

C40A1P Applications

  • Industrial control panel protection.
  • Machine tool power distribution.
  • Building electrical systems.
  • Automation equipment circuits.

C40A1P FAQs

7 frequently asked questions generated from this part’s specifications.
What is the voltage rating of the C40A1P circuit breaker?

480VAC.

What is the current rating?

40A.

What is the operating temperature range?

-40°C to +60°C.

What type of circuit breaker is it?

Magnetic-hydraulic with hydraulic delay.

What is the interrupting capacity?

10,000A under UL 489; note UL 1077 rating may be lower.

How is it mounted?

DIN rail mount.

What approvals does it have?

CE, UL1077, and UR.
