C330C102KGR5TA7303 This is a 1000pF, 2000V, X7R ceramic capacitor from Yageo in a radial leaded package. It features ±10% tolerance and is suitable for general purpose applications.
Mfr Part #:

C330C102KGR5TA7303

Available from 1 distributors
Mfr Name: Yageo
Yageo
This is a 1000pF, 2000V, X7R ceramic capacitor from Yageo in a radial leaded package. It features ±10% tolerance and is suitable for general purpose applications.
✓ Total Stock: 1,962 pcs

C330C102KGR5TA7303 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
1,962 pcs
On Request
1962 pcs On Request 1 On Request On Request 2134+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

C330C102KGR5TA7303 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Aging Rate
Applications
Automotive Grade
Capacitance
Dielectric Withstanding Voltage
Dissipation Factor
Features
Halogen Free
Height
Industrial Grade
Insulation Resistance
Lead Diameter
Lead Spacing
Lead Style
Length
Medical Grade
Military Grade
Mounting Type
Operating Temperature
SVHC Present
Standard Package Quantity
Tape & Reel
Temperature Coefficient
Tolerance
Voltage
Width
View Similar Products (0)

C330C102KGR5TA7303 Description

Short technical summary and product information.

The C330C102KGR5TA7303 is a ceramic capacitor from Yageo's GoldMax 300 Comm X7R HV series. It offers a capacitance of 1000 pF with a tolerance of ±10% and a rated DC voltage of 2000 V. The dielectric is X7R, providing a stable capacitance over a temperature range of -55°C to 125°C.



Key electrical characteristics include a dissipation factor of 2.5% maximum at 1 kHz and 1.0 Vrms, an insulation resistance of at least 100 GΩ, and an aging rate of 3% loss per decade hour. The capacitor is designed for high voltage applications and is RoHS and Halogen Free compliant.



The component is packaged in a radial through-hole configuration with formed leads. Maximum dimensions are 7.62 mm length, 10.16 mm height, and 5.08 mm thickness. Lead spacing is 5.08 mm, and lead diameter is 0.51 mm. Available in tape and reel packaging (305 mm) with 1500 units per reel.

C330C102KGR5TA7303 Quick Information

Product Type: Ceramic Capacitor
Series: GoldMax 300 Comm X7R HV
Canonical Name: C330C102KGR5TA7303 - Yageo GoldMax 300 Comm X7R HV Ceramic Capacitor
Subcategory: High Voltage Ceramic Capacitor

C330C102KGR5TA7303 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

C330C102KGR5TA7303 Features

  • 1000pF capacitance with ±10% tolerance.
  • Rated voltage of 2000V DC.
  • X7R temperature coefficient dielectric.
  • Radial through-hole package with formed leads.
  • RoHS and Halogen Free compliant.

C330C102KGR5TA7303 Applications

  • Ideal for high voltage power supply circuits.
  • Used in snubber and filtering applications.
  • Suitable for general purpose coupling and decoupling.
  • Common in industrial and consumer electronics.

C330C102KGR5TA7303 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance value of the C330C102KGR5TA7303?

1000 pF.

What is the voltage rating of the C330C102KGR5TA7303?

2000 V DC.

What is the temperature coefficient of this capacitor?

X7R.

What is the capacitance tolerance?

±10%.

What is the package type of the C330C102KGR5TA7303?

Radial through-hole with formed leads, lead spacing 5.08 mm.

What is the dissipation factor?

2.5% at 1 kHz 1.0Vrms.

What is the operating temperature range?

-55°C to 125°C.
