This Ground Fault Interrupter Circuit Breaker from American Electrical Inc., part number C30A2P-GFI, is rated for 30 Amps and 240 Volts. It features a 1+N pole configuration and is designed for DIN rail mounting, making it suitable for industrial electrical panels.
The breaker utilizes a magnetic/hydraulic operation, ensuring consistent performance unaffected by ambient temperature. It is recognized under UL 1077 and UL 1053 standards and is CE approved. The interrupting rating is 5 kA. Sensitivity is rated at 30 mA for CE and 22 mA for UL.
Key specifications include a width of 26mm and an operating temperature range of -40°C to +60°C. The trip curve is designated as 2. This component is ideal for applications requiring protection against ground faults, helping to prevent electric shocks and reduce fire risks.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 30A.
The voltage rating is 240V.
It has 1 pole.
It is a Ground Fault Interrupter Circuit Breaker.
It is designed for DIN rail mounting.
The operating temperature range is -40°C to +60°C.
It is approved by CE, UL1053, and UL1077.
