| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Voltage Rating | |
| Weight | |
| Width |
The American Electrical Inc. C2A1P-489 is a single-pole AC circuit breaker rated for 2 Amps and a maximum voltage of 240V. It features a compact 13 mm width and is designed for easy DIN rail mounting, making it suitable for various industrial and electrical applications.
This breaker employs hydraulic-magnetic technology for reliable operation and protection. It boasts a 10,000A interrupting capacity at 240V, ensuring safety in fault conditions. The operating temperature range is from -40°C to +60°C, allowing for use in diverse environments.
Compliance includes UL489, CE, and UR certifications, indicating adherence to relevant safety standards. The breaker is also listed as RoHS3 Compliant, REACH Unaffected, and Moisture Sensitivity Level 1.
The current rating is 2A.
The maximum operating voltage is 240V.
It is designed for DIN rail mounting.
It uses hydraulic-magnetic technology.
The interrupting capacity is 10,000A.
The operating temperature range is -40°C to +60°C.
It is certified by UL489, CE, and UR.
