C25A1P-80VDC The American Electrical Inc. C25A1P-80VDC is a 1-pole circuit breaker featuring a 25A current rating and 80VDC voltage rating. It utilizes a magnetic hydraulic delay mechanism.
Mfr Part #:

C25A1P-80VDC

Mfr Name: American Electrical Inc.
American Electrical Inc.
The American Electrical Inc. C25A1P-80VDC is a 1-pole circuit breaker featuring a 25A current rating and 80VDC voltage rating. It utilizes a magnetic hydraulic delay mechanism.
Stock on Request

C25A1P-80VDC Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Type
Approval Agency
Breaker Type
Current Rating
Current Rating (Amps)
Mounting Type
Number of Poles
SVHC Present
Voltage Rating
View Similar Products (0)

C25A1P-80VDC Description

Short technical summary and product information.

This American Electrical Inc. circuit breaker, part number C25A1P-80VDC, is designed for reliable protection in electrical systems. It offers a 25A current rating and a voltage rating of 80VDC, suitable for DC applications.



The breaker type is magnetic with a hydraulic delay, providing specific trip characteristics. It features a single pole configuration and a lever actuator for manual operation. The unit is designed for DIN rail mounting, facilitating easy integration into standard electrical panels.



Compliance certifications include CE and UL489, indicating adherence to safety standards. The RoHS status is RoHS3 Compliant, and it has an MSL of 1, signifying unlimited shelf life under standard conditions. REACH status is unaffected.

C25A1P-80VDC Quick Information

Product Type: Circuit Breaker
Canonical Name: American Electrical Inc. C25A1P-80VDC 1-Pole Magnetic Hydraulic Delay Circuit Breaker
Subcategory: Magnetic Hydraulic Delay

C25A1P-80VDC Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

C25A1P-80VDC Features

  • 25A current rating for DC applications.
  • 80VDC voltage rating.
  • Magnetic hydraulic delay trip mechanism.
  • Single pole, lever actuator.
  • DIN rail mounting type.

C25A1P-80VDC Applications

  • Overcurrent protection for 80VDC DC circuits.
  • DIN rail mount for industrial control panels.
  • Single pole magnetic hydraulic delay breaker.
  • UL489 approved for branch circuit protection.
  • Suitable for DC power distribution systems.

C25A1P-80VDC FAQs

7 frequently asked questions generated from this part’s specifications.
What is the current rating of the C25A1P-80VDC circuit breaker?

The current rating is 25A.

What is the voltage rating for the C25A1P-80VDC?

The voltage rating is 80VDC.

How many poles does the C25A1P-80VDC circuit breaker have?

It has 1 pole.

What type of breaker mechanism does the C25A1P-80VDC use?

It uses a Magnetic (Hydraulic Delay) breaker type.

What mounting type is used for the C25A1P-80VDC?

The mounting type is DIN Rail.

Is the C25A1P-80VDC RoHS compliant?

The RoHS status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for this part?

The MSL is 1 Unlimited.
