| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Height | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature Range | |
| Package / Case | |
| Termination | |
| Voltage Rating | |
| Width |
The American Electrical Inc. C20A2P-489 is a 2-pole circuit breaker designed for reliable electrical protection. It utilizes magnetic-hydraulic delay technology for its operation.
This circuit breaker has a current rating of 20A and a maximum voltage rating of 240VAC. It is designed for DIN rail mounting, making it suitable for industrial and panel applications. The compact width of 13mm allows for efficient use of space in enclosures.
Key specifications include a 20A current rating, 240V AC voltage rating, and 2 poles. The breaker type is magnetic with hydraulic delay. It is approved by UL489 and CE standards.
This component is suitable for applications requiring overcurrent protection in electrical systems where DIN rail mounting is preferred.
The current rating is 20A.
The maximum voltage rating is 240V AC.
It has 2 poles.
It uses Magnetic (Hydraulic Delay) technology.
The mounting type is DIN Rail.
The operating temperature range is -40°C to +60°C.
It is approved by CE, UL489, and UR.
