| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Height | |
| Insulation Resistance | |
| Length | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature Range | |
| Voltage Rating | |
| Weight | |
| Width |
The American Electrical Inc. C20A1P-489 is a single-pole circuit breaker designed for DIN rail mounting. It operates at a voltage rating of 240V AC and has a current rating of 20A. This breaker utilizes magnetic-hydraulic delay technology for reliable circuit protection.
With a compact 13 mm width, it is suitable for space-constrained applications. The C20A1P-489 is UL489 approved, ensuring compliance with safety standards for industrial electrical accessories. Its technical specifications include an interrupting capacity of 10,000A at 120V, a dielectric strength of 1500V, and an insulation resistance of 100 Megaohm. The operating temperature range is from -40°C to +60°C.
This circuit breaker is also CE compliant. It is designed for industrial electrical applications where robust and reliable overcurrent protection is required. The lever actuator allows for easy operation.
The current rating is 20A.
The voltage rating is 240V.
It has 1 pole.
It is designed for DIN rail mounting.
The operating temperature range is -40°C to +60°C.
The approval agencies are CE, UL489, and UR.
