| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Height | |
| Insulation Resistance | |
| Length | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage Rating | |
| Weight | |
| Width |
This American Electrical Inc. C20A1P circuit breaker is a single-pole unit with a 20A current rating and a maximum voltage rating of 480V. It utilizes hydraulic-magnetic technology for reliable operation.
The breaker is designed for DIN rail mounting, making it suitable for industrial control panels and electrical enclosures. Its compact 13 mm width allows for space-saving installations.
Key specifications include a 1-pole configuration, 480V maximum voltage, and a 20A current rating. The interrupting capacity is rated at 5000A at 120V, 1000A at 277V, and 1000A at 480V. The operating temperature range is -40°C to +60°C.
This circuit breaker is UL1077 approved, ensuring compliance with safety standards for supplementary protection. It is also RoHS3 compliant and has an MSL of 1.
The current rating is 20A.
The maximum voltage rating is 480V.
It is designed for DIN rail mounting.
It uses hydraulic-magnetic technology.
The operating temperature range is -40°C to +60°C.
The interrupting capacity is 1000A at 480V.
Yes, it is RoHS3 Compliant.
