| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
16 pcs
|
16 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Capacitance | |
| Features | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Package / Case | |
| Temperature Coefficient | |
| Thickness (Max) | |
| Tolerance | |
| Voltage | |
| Width |
The C1608C0G1H121K080AA is a multilayer ceramic chip capacitor (MLCC) from TDK Corporation. It offers a nominal capacitance of 120pF with a tolerance of ±10% and is rated for a DC voltage of 50V. The capacitor uses C0G (NP0) dielectric, which provides a stable temperature coefficient with minimal capacitance change over the operating temperature range of -55°C to +125°C. This makes it suitable for applications requiring high stability and low loss.
The component features low equivalent series inductance (ESL), making it effective for high-frequency decoupling and filtering circuits. It is housed in a standard 0603 (1608 Metric) surface-mount package with dimensions of 1.60mm x 0.80mm and a maximum thickness of 0.90mm. The MLCC is designed for general-purpose use in commercial and industrial electronic equipment.
Typical applications include coupling, bypass, timing, and filtering in consumer electronics, telecommunications equipment, and industrial control systems. The surface-mount form factor enables automated assembly for high-density PCB designs.
120 pF
50 V
C0G, NP0
±10%
0603 (1608 Metric)
-55°C to 125°C
Yes, it features low Equivalent Series Inductance (ESL).
