This American Electrical Inc. C15A2P-GFI is a 15 Amp, 240 Volt ground fault interrupter circuit breaker. It features a DIN rail mounting type and a lever actuator. The breaker operates on a magnetic/hydraulic principle, ensuring consistent performance regardless of ambient temperature.
With a 15A current rating and 240V voltage rating, this circuit breaker is suitable for various electrical protection applications. It is recognized by CE, UL1053, and UL1077 approval agencies. The device has an interrupting rating of 5 kA.
Key specifications include a width of 26mm and an operating temperature range from -40°C to +60°C. The sensitivity for CE is 30mA, and for UL, it is 22mA. It is a 1-pole + neutral breaker.
The current rating is 15A.
The voltage rating is 240V.
It has 1 pole plus neutral.
It is a Ground Fault circuit breaker.
The mounting type is DIN Rail.
The operating temperature range is -40°C to +60°C.
It is approved by CE, UL1053, and UL1077.
