C15A1P-80VDC The American Electrical Inc. C15A1P-80VDC is a 1-pole, 15A, 80VDC circuit breaker with a magnetic hydraulic delay. It is designed for DIN rail mounting.
Mfr Part #:

C15A1P-80VDC

Mfr Name: American Electrical Inc.
American Electrical Inc.
The American Electrical Inc. C15A1P-80VDC is a 1-pole, 15A, 80VDC circuit breaker with a magnetic hydraulic delay. It is designed for DIN rail mounting.
Stock on Request

C15A1P-80VDC Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Actuator Type
Approval Agency
Automotive Grade
Breaker Type
Current Rating
Current Rating (Amps)
Industrial Grade
Medical Grade
Military Grade
Mounting Type
Number of Poles
SVHC Present
Voltage Rating
View Similar Products (0)

C15A1P-80VDC Description

Short technical summary and product information.

The American Electrical Inc. C15A1P-80VDC is a single-pole circuit breaker designed for DC applications. It features a magnetic hydraulic delay mechanism for reliable operation and is rated for a maximum voltage of 80VDC and a current of 15A.



This circuit breaker is suitable for DIN rail mounting, making it easy to integrate into control panels and electrical enclosures. It is manufactured by CBI and has passed rigorous design and manufacturing standards.



The C15A1P-80VDC is approved by CE, UL489, and UR, indicating compliance with relevant safety and performance standards. Its compact design offers an advantage in space-constrained applications.

C15A1P-80VDC Quick Information

Product Type: Circuit Breaker
Canonical Name: American Electrical Inc. C15A1P-80VDC Magnetic (Hydraulic Delay) Circuit Breaker
Subcategory: DC Circuit Breakers

C15A1P-80VDC Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

C15A1P-80VDC Features

  • 15A current rating for DC circuits.
  • 80VDC maximum operating voltage.
  • Magnetic hydraulic delay for protection.
  • Single-pole design for simplicity.
  • DIN rail mounting for easy installation.

C15A1P-80VDC Applications

  • Ideal for DC power distribution.
  • Suitable for control panel integration.
  • Used in low-voltage DC systems.
  • Provides overcurrent protection.

C15A1P-80VDC FAQs

7 frequently asked questions generated from this part’s specifications.
What is the current rating of the C15A1P-80VDC?

15A.

What is the voltage rating?

80VDC.

What type of circuit breaker is this?

Magnetic (Hydraulic Delay) circuit breaker.

How many poles does it have?

1 pole.

What is the mounting style?

DIN Rail.

What approvals does it have?

CE, UL489, and UR.

What is the actuator type?

Lever.
