| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Voltage Rating |
This American Electrical Inc. C10A2P-489 is a 2-pole circuit breaker designed for reliable circuit protection. It features a 10A current rating and a maximum operating voltage of 240VAC, with UL489 and UR approvals.
The breaker employs magnetic-hydraulic technology for consistent performance and includes a lever actuator for manual operation. Its compact 13mm width makes it suitable for DIN rail mounting, facilitating efficient panel assembly. The operating temperature range is -40°C to +60°C, ensuring functionality in various environments.
With an interrupting capacity of 10,000A at 120V, this circuit breaker provides robust protection against overcurrents. It also meets RoHS3 compliance and has an MSL of 1, indicating suitability for a wide range of industrial and commercial applications.
The breaker is rated for 240VAC, 277V, and 480V maximum.
-40°C to +60°C.
2 poles.
10,000A at certain conditions, 5000A at 120V, and 1000A at 277V and 480V.
Lever actuator.
DIN rail.
1500V at 50/60 Hz.
