This American Electrical Inc. C10A1P-489 is a single-pole circuit breaker designed for DIN rail mounting. It features a 10A current rating and a maximum voltage of 240V, making it suitable for various electrical protection applications.
The breaker employs hydraulic-magnetic technology, providing consistent performance across a wide operating temperature range of -40°C to +60°C. Its robust construction ensures a dielectric strength of 1500V and an insulation resistance of 100 MOhm.
With an interrupting capacity of 10,000A at 120V, this UL489 listed component offers reliable protection against overcurrents. It is also compliant with RoHS3 standards and has an MSL of 1.
Key specifications include its compact 13mm width and lever actuator type. This circuit breaker is an ideal choice for applications requiring dependable overcurrent protection in a compact, DIN rail mountable form factor.
The current rating is 10A.
The maximum voltage rating is 240V.
It has 1 pole.
It requires DIN rail mounting.
The operating temperature range is -40°C to +60°C.
It is RoHS3 Compliant.
