C052C472K1R5TA C052C472K1R5TA is a radial leaded ceramic capacitor from Yageo with 4700 pF capacitance, 100 VDC rating, and ±10% tolerance.
Mfr Part #:

C052C472K1R5TA

Available from 1 distributors
Mfr Name: Yageo
Yageo
C052C472K1R5TA is a radial leaded ceramic capacitor from Yageo with 4700 pF capacitance, 100 VDC rating, and ±10% tolerance.
✓ Total Stock: 880 pcs

C052C472K1R5TA Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
880 pcs
On Request
880 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

C052C472K1R5TA Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Capacitance
Dielectric Withstanding Voltage
Dissipation Factor
Halogen Free
Industrial Grade
Insulation Resistance
Lead Spacing
Lead Style
Medical Grade
Military Grade
Operating Temperature Range
SVHC Present
Tape & Reel
Temperature Coefficient
View Similar Products (0)

C052C472K1R5TA Description

Short technical summary and product information.

The C052C472K1R5TA is a radial leaded ceramic capacitor from Yageo's LDD Comm X7R series. It offers 4700 pF capacitance with ±10% tolerance and is rated for 100 VDC operation. The X7R dielectric provides stable capacitance over a temperature range of -55°C to +125°C with a maximum capacitance change of ±15%.



The capacitor features a dissipation factor of 2.5% maximum at 1 kHz and 25°C, and a minimum insulation resistance of 213 MΩ. It can withstand 250 VDC dielectric strength. Body dimensions are 4.83 mm length, 4.83 mm height, and 2.29 mm thickness, with a lead spacing of 5.08 mm and minimum lead length of 31.75 mm. Termination is tin-plated.



Packaging is bulk in bags with a standard quantity of 100 pieces. The component is RoHS with exemptions and contains REACH SVHC (Lead). It is suitable for general purpose applications requiring a reliable radial leaded ceramic capacitor.

C052C472K1R5TA Quick Information

Product Type: Ceramic Capacitor
Series: LDD Comm X7R
Canonical Name: C052C472K1R5TA — 4700 pF, 100 V, ±10%, X7R Radial Ceramic Capacitor
Subcategory: Radial Leaded MLCC

C052C472K1R5TA Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Compliant
Lead Free: Yes

C052C472K1R5TA Features

  • 4700 pF capacitance with ±10% tolerance.
  • Rated for 100 VDC operation.
  • X7R dielectric for stable temperature performance.
  • Radial leaded package with 5.08 mm spacing.
  • Tin-plated termination for solderability.

C052C472K1R5TA Applications

  • Decoupling and bypass in general purpose electronics.
  • Filtering in audio and signal circuits.
  • Coupling and timing applications.
  • Voltage divider networks.

C052C472K1R5TA FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance of the C052C472K1R5TA?

4700 pF

What is the rated voltage of this capacitor?

100 VDC

What is the temperature coefficient?

X7R

What is the capacitance tolerance?

±10%

What is the available packaging?

Bulk, Bag with standard quantity of 100.

What is the lead spacing?

5.08 mm

What is the operating temperature range?

-55°C to +125°C
