BZX84C75LT1G The BZX84C75LT1G is a 75V Zener diode from ON Semiconductor with ±6% tolerance and 250mW power dissipation in a SOT-23-3 surface mount package.
Mfr Part #:

BZX84C75LT1G

Available from 4 distributors
Mfr Name: On Semiconductor
On Semiconductor
The BZX84C75LT1G is a 75V Zener diode from ON Semiconductor with ±6% tolerance and 250mW power dissipation in a SOT-23-3 surface mount package.
✓ Total Stock: 47,158 pcs

BZX84C75LT1G Available from 4 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

BZX84C75LT1G Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Current
Forward Voltage
Impedance (Max) (Zzt)
Industrial Grade
Medical Grade
Military Grade
Mounting Type
Operating Temperature
Operating Temperature Range
Package / Case
Power
Power Dissipation
SVHC Present
Storage Temperature
Supplier Device Package
Tape & Reel
Tolerance
Voltage
View Similar Products (0)

BZX84C75LT1G Description

Short technical summary and product information.

The BZX84C75LT1G is a 75V Zener diode from ON Semiconductor designed for voltage regulation in space-constrained applications. With a nominal Zener voltage of 75V and ±6% tolerance, this device provides accurate voltage clamping. It features a maximum power dissipation of 250mW on standard FR-4 or FR-5 boards, with a maximum Zener impedance of 255Ω and a reverse leakage current of only 50nA at 52.5V.



The diode is housed in a SOT-23-3 surface mount package (also known as TO-236), which allows for automated board assembly and high-density mounting. The operating junction temperature range spans -65°C to 150°C, ensuring reliability in harsh environments. Forward voltage is 900mV at 10mA.



Typical applications include cellular phones, handheld portables, and other portable electronics requiring stable voltage regulation in a small footprint. The device is RoHS compliant and lead-free (Pb-Free).

BZX84C75LT1G Quick Information

Product Type: Zener Diode
Series: BZX84CxxxLT1G
Canonical Name: ON Semiconductor BZX84C75LT1G 75V Zener Diode
Subcategory: Single Zener Diode

BZX84C75LT1G Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

BZX84C75LT1G Features

  • 75V nominal Zener voltage with ±6% tolerance.
  • 250mW power dissipation rating on FR-4/5 board.
  • Maximum 255Ω Zener impedance at test current.
  • 50nA reverse leakage current at 52.5V.
  • Surface mount SOT-23-3 (TO-236) package.

BZX84C75LT1G Applications

  • Voltage regulation in portable electronic devices.
  • Protection circuits in handheld consumer products.
  • Cellular phone power management applications.
  • High-density printed circuit board designs.
  • General purpose Zener diode voltage regulation.

BZX84C75LT1G FAQs

7 frequently asked questions generated from this part’s specifications.
What is the Zener voltage of BZX84C75LT1G?

The nominal Zener voltage is 75V with a tolerance of ±6%.

What is the forward voltage of this diode?

The maximum forward voltage is 900mV at 10mA forward current.

What package does the BZX84C75LT1G come in?

It is available in a SOT-23-3 surface mount package (also designated as TO-236, SC-59).

What is the power dissipation rating?

The maximum power dissipation is 250mW when mounted on FR-4 or FR-5 board (datasheet rating).

What is the reverse leakage current?

Maximum 50nA at 52.5V reverse voltage.

What is the Zener impedance?

Maximum Zener impedance (Zzt) is 255Ω.

What is the operating temperature range?

-65°C to 150°C junction temperature.
