BZT52C30S-7 The Diodes Incorporated BZT52C30S-7 is a Zener diode with a 30V nominal voltage and 200mW power rating. It features a ±6.67% tolerance and is housed in a SOD-323 surface mount package.
Mfr Part #:

BZT52C30S-7

Available from 1 distributors
Mfr Name: Diodes Incorporated
Diodes Incorporated
The Diodes Incorporated BZT52C30S-7 is a Zener diode with a 30V nominal voltage and 200mW power rating. It features a ±6.67% tolerance and is housed in a SOD-323 surface mount package.
✓ Total Stock: 2,565 pcs
$ Price Range: $0.02

BZT52C30S-7 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
2,565 pcs
On Request
2565 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

BZT52C30S-7 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mounting Type
Operating Temperature
Supplier Device Package
Tolerance
View Similar Products (0)

BZT52C30S-7 Description

Short technical summary and product information.

The BZT52C30S-7 from Diodes Incorporated is a single Zener diode designed for various electronic applications. It offers a nominal Zener voltage of 30V with a tight tolerance of ±6.67%. The diode has a maximum power dissipation of 200mW, making it suitable for low-power voltage regulation and reference circuits.



This component features a low reverse leakage current of 100 nA at 21V and a forward voltage of 900 mV at 10 mA. It operates within a temperature range of -65°C to 150°C. The BZT52C30S-7 is packaged in a compact SOD-323 (SC-76) surface mount case, facilitating integration into densely populated circuit boards.



Its specifications make it a reliable choice for applications requiring stable voltage references or simple voltage clamping. The surface mount package is ideal for automated assembly processes.

BZT52C30S-7 Quick Information

Product Type: Zener Diode
Series: BZT52C30S
Canonical Name: BZT52C30S-7
Subcategory: Zener Diodes

BZT52C30S-7 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

BZT52C30S-7 Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

BZT52C30S-7 Features

  • 30V nominal Zener voltage rating.
  • 200mW maximum power dissipation.
  • ±6.67% voltage tolerance.
  • SOD-323 surface mount package.
  • Wide operating temperature range.

BZT52C30S-7 Applications

  • Voltage regulation circuits.
  • Voltage reference applications.
  • Low power circuit protection.
  • Signal clamping applications.

BZT52C30S-7 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the nominal Zener voltage of the BZT52C30S-7?

30V.

What is the power dissipation rating of the BZT52C30S-7?

200mW.

What is the package type for the BZT52C30S-7?

SOD-323.

What is the operating temperature range of the BZT52C30S-7?

-65°C to 150°C.

What is the reverse leakage current of the BZT52C30S-7?

100nA at 21V.

What is the forward voltage of the BZT52C30S-7?

900mV at 10mA.
