Mfr Part #:

BUX67C

Mfr Name: HAR

The BUX67C is a Silicon NPN Power Transistor from HAR. It is designed for high-speed switching and linear amplifier applications.

✓ Total Stock: 17 pcs

$ Price Range: $0.77

BUX67C Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Partservice ✓ Non-Authorised Inventory information	17 pcs On Request	17 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

BUX67C Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	HAR
Junction Temperature	200℃
Storage Temperature	-65℃ to 200℃

View Similar Products (0)

BUX67C Description

Short technical summary and product information.

The BUX67C is a Silicon NPN Power Transistor manufactured by HAR. It is engineered for applications requiring high-speed switching and linear amplification, such as high-voltage operational amplifiers, switching regulators, converters, deflection stages, and high-fidelity amplifiers.

Key electrical characteristics include a maximum Collector-Base Voltage (V_CBO) of 400V and a maximum Collector-Emitter Voltage (V_CEO) of 350V. The continuous collector current (I_C) is rated at 2A, with a peak collector current (I_CP) of 5A. Power dissipation (P_D) is 35W at a case temperature of 25℃, and the junction temperature (T_J) can reach up to 200℃.

This transistor features a maximum Collector-Emitter Saturation Voltage (V_CE(sat)) of 2.5V at 1A collector current and 0.15A base current. The DC Current Gain (h_FE) ranges from a minimum of 10 to a maximum of 150 when tested at 1A collector current and 5V collector-emitter voltage. The Current Gain-Bandwidth Product (f_T) is 25MHz at 0.5A collector current and 10V collector-emitter voltage.

The BUX67C is suitable for various electronic designs where robust power handling and fast switching capabilities are essential.

BUX67C Quick Information

Product Type: Transistor

Canonical Name: BUX67C Silicon NPN Power Transistor

Subcategory: Single

BUX67C Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

BUX67C Estimated Pricing

Qty	Low	High
1+	$0.77	$0.77

Estimated market price range - modelled values for guidance only, not live distributor offers.

BUX67C Features

High voltage NPN power transistor.
Designed for switching applications.
Continuous collector current of 2A.
Maximum power dissipation of 35W.
High junction temperature rating.

BUX67C Applications

Used in high-voltage amplifiers.
Suitable for switching regulators.
Applicable in power converters.
Designed for deflection stages.
Ideal for high fidelity amplifiers.

BUX67C FAQs

6 frequently asked questions generated from this part’s specifications.

What is the maximum collector-emitter voltage for the BUX67C?

The maximum collector-emitter voltage (V_CEO) for the BUX67C is 350V.

What is the continuous collector current rating of the BUX67C?

The continuous collector current (I_C) for the BUX67C is 2A.

What is the maximum power dissipation of the BUX67C?

The maximum power dissipation (P_D) for the BUX67C is 35W at a case temperature of 25℃.

What is the maximum junction temperature for the BUX67C?

The maximum junction temperature (T_J) for the BUX67C is 200℃.

What is the DC Current Gain (h_FE) range for the BUX67C?

The DC Current Gain (h_FE) for the BUX67C ranges from 10 to 150.

What is the Current Gain-Bandwidth Product (f_T) of the BUX67C?

The Current Gain-Bandwidth Product (f_T) for the BUX67C is 25MHz.

BUX67C Alternate Parts

Same form/fit/function or matching attribute configuration across different manufacturers.

View All Alternate Parts

2N3792

Central Semiconductor Corp

The 2N3792 is a PNP power transistor manufactured by Central Semiconductor Corp. It is designed for medium-speed switching and amplifier applications.

View Part
