Mfr Part #:

BTS707

Mfr Name: Infineon

The Infineon BTS707 is a smart two-channel highside power switch designed for 12V and 24V DC grounded loads. It offers integrated protective functions and diagnostic feedback.

✓ Total Stock: 12 pcs

$ Price Range: $0.32

BTS707 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Speed Components Ltd ✓ Non-Authorised Inventory information	12 pcs On Request	12 pcs	On Request	1	On Request	On Request	06+30	On Request	On Request

BTS707 Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Infineon
Operating Voltage	5.8 ... 58 V

View Similar Products (0)

BTS707 Description

Short technical summary and product information.

The Infineon BTS707 is a versatile N-channel vertical power FET, functioning as a smart two-channel highside power switch. It is designed for µC-compatible applications with diagnostic feedback, suitable for both 12V and 24V DC grounded loads. This device integrates several protective functions, including overload protection, current limitation, short-circuit protection, thermal shutdown, and overvoltage protection up to 65V.

The BTS707 features a low on-state resistance, with 250 mΩ for a single active channel and 125 mΩ when two channels are paralleled. The nominal load current is 1.9A for a single channel and 2.8A for paralleled channels. It also provides open load detection in the OFF-state and a diagnostic feedback output.

This power switch is particularly suitable for inductive loads and can replace electromechanical relays, fuses, and discrete circuits. It operates within a voltage range of 5.8V to 58V. The device is housed in a 20-SOIC package, designed for surface mounting.

Key features include reverse battery protection (with external current limiting), fast demagnetization of inductive loads, and protection against loss of ground and Vbb. Its CMOS-compatible input simplifies integration with microcontrollers.

BTS707 Quick Information

Product Type: Power Distribution Switch

Series: BTS707

Canonical Name: BTS707 Smart Two Channel Highside Power Switch

Subcategory: Load Drivers

BTS707 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

BTS707 Estimated Pricing

Qty	Low	High
1+	$0.32	$0.32

Estimated market price range - modelled values for guidance only, not live distributor offers.

BTS707 Features

Two channel highside power switch.
Overvoltage protection up to 65V.
Operating voltage 5.8V to 58V.
Low on-state resistance.
Integrated protective functions.

BTS707 Applications

Suitable for 12V and 24V DC loads.
Ideal for inductive load applications.
Replaces electromechanical relays.
Used with microcontrollers for power switching.

BTS707 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the overvoltage protection rating for the Infineon BTS707?

The overvoltage protection rating for the Infineon BTS707 is 65 V.

What is the operating voltage range for the BTS707?

The operating voltage range for the BTS707 is 5.8 V to 58 V.

What is the typical on-state resistance for the BTS707 with one active channel?

The typical on-state resistance for the BTS707 with one active channel is 250 mΩ.

What is the typical on-state resistance for the BTS707 with two parallel active channels?

The typical on-state resistance for the BTS707 with two parallel active channels is 125 mΩ.

What is the nominal load current for the BTS707 with one active channel?

The nominal load current for the BTS707 with one active channel is 1.9 A.

What is the nominal load current for the BTS707 with two parallel active channels?

The nominal load current for the BTS707 with two parallel active channels is 2.8 A.

What is the RoHS status for the BTS707?

The BTS707 is RoHS3 Compliant.
