The BSO040N03MSGXUMA1 is an N-Channel power MOSFET from Infineon Technologies, part of the OptiMOS 3 M-Series. It is designed for high-frequency switching applications, with a drain-source voltage rating of 30V and a continuous drain current of 16A (steady state at VGS=10V, TA=25°C). The device offers a very low on-resistance of 4 mOhm (max) at VGS=10V, ID=20A, and is optimized for 5V driver applications.
This MOSFET supports a wide range of gate drive voltages, with a maximum gate-source voltage of ±20V. It features a low gate charge (Qg) of 73 nC (max) at VGS=10V, and a typical input capacitance of 4300 pF at VDS=15V, making it suitable for high-frequency switching. The device is 100% avalanche tested, with a single-pulse avalanche energy rating of 150 mJ.
The BSO040N03MSGXUMA1 is available in an 8-SOIC (0.154", 3.90mm Width) surface-mount package, with a supplier device package of PG-DSO-8. It is designed for consumer-level applications, and is RoHS compliant, Pb-free, and halogen-free according to IEC61249-2-21.
This MOSFET is suitable for a variety of applications, including notebook, VGA, and POL power supplies, as well as high-frequency SMPS. Its low on-resistance and gate charge product (FOM) make it an excellent choice for power management and switching circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.19 | $2.19 |
| 10+ | $1.40 | $1.40 |
| 100+ | $0.95 | $0.95 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The drain-source voltage (Vdss) is 30 V (maximum).
The continuous drain current is 16 A at VGS=10V, TA=25°C, steady state. It can handle up to 20 A for 10 seconds under the same conditions.
The operating temperature range is -55°C to 150°C (junction temperature).
Yes, the BSO040N03MSGXUMA1 is RoHS compliant (RoHS3) and halogen-free according to IEC61249-2-21.
The maximum on-resistance is 4 mOhm at VGS=10V, ID=20A, and 4.9 mOhm at VGS=4.5V, ID=18A.
The package is 8-SOIC (0.154", 3.90mm Width) with a supplier device package of PG-DSO-8.
