| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,020 pcs
|
6020 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Gate Charge (Qg) (Max) @ Vgs | |
| Halogen Free | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation (Max) | |
| Rds On (Max) @ Id, Vgs | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
The BSC067N06LS3GATMA1 is an N-Channel enhancement mode power MOSFET from Infineon Technologies, part of the OptiMOS 3 family. It is designed for high-frequency switching and synchronous rectification in DC/DC converters.
Key electrical specifications include a maximum drain-source voltage of 60V, continuous drain current of 79A at 25°C case temperature, and a low on-resistance of 6.7mOhm at 10V gate drive. The device is logic level capable with a gate threshold voltage of 2.2V.
The MOSFET is housed in a PG-TDSON-8-5 (8-PowerTDFN) surface mount package. It is RoHS compliant and halogen-free according to IEC61249-2-21.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.21 | $1.21 |
| 10+ | $0.75 | $0.75 |
| 100+ | $0.50 | $0.50 |
| 500+ | $0.50 | $0.50 |
| 5,000+ | $0.50 | $0.50 |
| 10,000+ | $0.28 | $0.28 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum drain-source voltage is 60V.
The continuous drain current is 79A at 25°C case temperature with 10V gate drive.
The maximum on-resistance is 6.7mOhm at 10V gate drive and 50A drain current.
It comes in a PG-TDSON-8-5 (8-PowerTDFN) surface mount package.
Yes, it is RoHS compliant and halogen-free according to IEC61249-2-21.
The operating junction temperature range is -55°C to 150°C.
The maximum gate threshold voltage is 2.2V at 35µA drain current.
