BQ32002DR Texas Instruments BQ32002DR is a real-time clock with calendar, I²C interface, and automatic backup supply. It operates from 1.4V to 3.6V with typical 65µA current and is available in an 8-SOIC package.
Mfr Part #:

BQ32002DR

Available from 4 distributors
Mfr Name: Texas Instruments
Texas Instruments
Texas Instruments BQ32002DR is a real-time clock with calendar, I²C interface, and automatic backup supply. It operates from 1.4V to 3.6V with typical 65µA current and is available in an 8-SOIC package.
✓ Total Stock: 79,452 pcs
$ Price Range: $0.68

BQ32002DR Available from 4 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
45,200 pcs
On Request
45200 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
30,000 pcs
On Request
30000 pcs On Request 1 On Request On Request 21+ On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
2,810 pcs
On Request
2810 pcs On Request 1 On Request On Request On Request On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
1,442 pcs
On Request
1442 pcs On Request 1 On Request On Request 21+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

BQ32002DR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Date Format
Features
Interface
Mounting Type
Operating Temperature
SVHC Present
Supplier Device Package
Time Format
Type
Voltage
View Similar Products (0)

BQ32002DR Description

Short technical summary and product information.

The BQ32002DR from Texas Instruments is a real-time clock (RTC) with integrated calendar and I²C interface. It includes automatic switchover to a backup supply (capacitor or non-rechargeable battery) and a trickle charger. Key features include leap-year compensation, square wave output, and programmable calibration adjustment from -63 ppm to +126 ppm. The device also features integrated oscillator-fail detection with a flag register.



The RTC operates from a supply voltage range of 1.4V to 3.6V, with a typical timekeeping current of 65 µA at 3.3V. It supports I²C serial communication up to 400 kHz and requires an external 32.768 kHz crystal. The operating temperature range is -40°C to +85°C.



The BQ32002DR is housed in an 8-pin SOIC package (8-SOIC, 3.90mm width) and is surface-mountable. It is designed for applications requiring accurate timekeeping with backup power, such as industrial controls, consumer electronics, and battery-powered systems.

BQ32002DR Quick Information

Product Type: Real-Time Clock (RTC)
Canonical Name: BQ32002DR Real-Time Clock (RTC) with I²C Interface
Subcategory: Clock/Calendar

BQ32002DR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

BQ32002DR Estimated Pricing

Qty Low High
1+ $0.68 $0.68

Estimated market price range - modelled values for guidance only, not live distributor offers.

BQ32002DR Features

  • I²C interface supports serial clock up to 400 kHz.
  • Automatic switchover to backup supply with trickle charger.
  • Programmable calibration adjustment from -63 to +126 ppm.
  • Integrated oscillator-fail detection with OF flag.
  • Operates from 1.4V to 3.6V with 65µA typical current.

BQ32002DR Applications

  • Ideal for battery-powered timekeeping applications.
  • Used in industrial control systems with backup power.
  • Suitable for consumer electronics requiring calendar and alarm.
  • Can be used in automotive systems (within temperature range).

BQ32002DR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage range for the BQ32002DR?

The supply voltage range is 1.4V to 3.6V.

What package does the BQ32002DR come in?

It comes in an 8-SOIC (8-pin small outline integrated circuit) package with 3.90mm width.

What is the operating temperature range?

The operating temperature range is -40°C to +85°C.

Is the BQ32002DR RoHS compliant?

Yes, it is listed as RoHS3 compliant (unverified).

What interface does the BQ32002DR use?

It uses an I²C (2-wire serial) interface.

What is the typical timekeeping current?

The typical timekeeping current is 65 µA at 3.3V.

What crystal frequency is required?

The device requires a 32.768 kHz crystal.
