The Bel Power Solutions BQ2320-9R is a 120W DC-DC converter designed for ITE (Commercial) and Railway applications. It features a wide input voltage range of 14.4 to 36 VDC and provides two isolated 12VDC outputs, each capable of delivering 9.2A.
This converter boasts an efficiency of 87.5% and operates within a temperature range of -40°C to 71°C. Its dimensions are 171.0mm in length, 111.0mm in width, and 19.8mm in height. The unit is enclosed, conformal coated, and designed for chassis mounting.
Safety approvals include CE, CSA, EN, IEC, TUV, and UL, with compliance to safety standard 62368. The RoHS status is RoHS3 Compliant, and it has a Moisture Sensitivity Level (MSL) of 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $639.66 | $639.66 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The BQ2320-9R DC-DC converter has a power output of 120W.
The input voltage range for the BQ2320-9R is 14.4 to 36 VDC.
The BQ2320-9R provides dual 12VDC outputs.
The BQ2320-9R has 2 outputs.
The operating temperature range is -40°C to 71°C.
The BQ2320-9R requires chassis mounting.
Yes, the BQ2320-9R is RoHS3 Compliant.
