The ROHM Semiconductor BP5718A12 is an enclosed AC/DC converter designed for board mount applications. It features a 12V nominal output voltage and a rated output current of 1A, providing a total output power of 12W. The converter accepts an input voltage range of 80 to 138 VAC and boasts a typical efficiency of 83%.
This converter is suitable for ITE (Commercial) applications and operates within a temperature range of -25°C to 80°C with derating. Its dimensions are 32.5mm in length, 9.5mm in width, and 21.5mm in height. The package is an 11-SIP Module with 7 leads, designed for through-hole mounting.
Key electrical characteristics include a maximum input voltage of 500V and a maximum input current of 500mA. The device also features a withstand voltage of 2.5KV between primary and secondary sides. The maximum allowable surface temperature is 105°C, and the storage temperature range is -40°C to 105°C.
The BP5718A12 provides a nominal output of 12V at 1000mA.
The input voltage range is 80 to 138 VAC.
The operating temperature range is -25°C to 80°C with derating.
The BP5718A12 is housed in an 11-SIP module with 7 leads and is through-hole mountable.
The typical efficiency is 83%.
The switching frequency is 100kHz.
