| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Body Material | |
| Dimensions | |
| Fuse Type | |
| Mounting Type | |
| Temperature Rating | |
| Termination Style | |
| Voltage Rating |
The OptiFuse BLR-I-504 is a compact fuse block designed to protect four DC circuits using regular ATO/ATC style blade fuses. It features M4 screw terminals for line-side connections and #10-32 threaded studs for load-side connections, ensuring secure wiring. This fuse block has a current rating of 30A per circuit and a combined maximum input current of 100A, with a voltage rating of 32VDC.
The body is constructed from black PBT (UL94V-0), and it comes with a transparent PC (UL94V-2) insulating cover that protects against short circuits, dirt, dust, and splashes. The operating temperature range is -20°C to 85°C. The dimensions are 1.85 inches in length, 1.02 inches in height, and 3.94 inches in width.
This fuse block is suitable for various DC distribution systems, particularly in applications requiring compact circuit protection. The screw terminals provide a reliable connection, making it beneficial for demanding environments like emergency vehicles.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating for each circuit is 30A.
The maximum combined current rating for all circuits is 100A.
The voltage rating is 32VDC.
It accepts regular ATO/ATC style blade fuses.
It has M4 screw terminals for the line side and #10-32 threaded studs for the load side.
The operating temperature range is -20°C to 85°C.
The dimensions are 1.85 inches in length, 1.02 inches in height, and 3.94 inches in width.
