| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Body Material | |
| Cap Material | |
| Contact Finish | |
| Contact Material | |
| Current Rating | |
| Current Rating (Amps) | |
| Flammability Rating | |
| For Use With | |
| Fuse Size | |
| Fuse Type | |
| Fuseholder Type | |
| Indicating | |
| Lead Style | |
| Mounting Type | |
| Number of Circuits | |
| Operating Temperature Range | |
| Orientation | |
| Panel Thickness Range | |
| Termination Style | |
| Voltage |
The OptiFuse BLR-I-301 is a single-pole indicating fuse block designed for use with ATC and ATO standard automotive blade fuses. It is rated for 30A at 24V DC and provides a reliable circuit protection solution for automotive, marine, and industrial applications.
The fuse block features a red LED indicator that illuminates when the fuse is blown, simplifying troubleshooting. The body is made of nylon with a UL94 V-2 flammability rating, and the cap is polycarbonate with the same rating. Contacts are tin-plated brass with 0.250" (6.3mm) quick connect terminals for easy wiring.
Mounting is via a snap-in panel mount design that accommodates panel thicknesses from 0.5 mm to 7.0 mm. The operating temperature range is -20°C to +85°C. The orientation supports both horizontal and vertical fuse insertion.
| Qty | Low | High |
|---|---|---|
| 1+ | $10.67 | $10.67 |
| 10+ | $9.39 | $9.39 |
| 50+ | $8.75 | $8.75 |
| 100+ | $8.11 | $8.11 |
| 250+ | $7.97 | $7.97 |
| 500+ | $7.82 | $7.82 |
| 1,000+ | $7.68 | $7.68 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
30 A
24 V DC
ATC and ATO standard automotive blade fuses (0.75" L x 0.2" W)
Yes, it has a red LED indicator.
-20°C to +85°C
Panel mount with snap-in installation, accepting panel thickness from 0.5 mm to 7.0 mm.
Quick Connect - 0.250" (6.3mm)
