| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Body Material | |
| Compatible Fuse Types | |
| Contact Finish | |
| Contact Material | |
| Current Rating (@ 125 VAC) | |
| Current Rating (@ 250 VAC) | |
| Current Rating (Amps) | |
| Flammability Rating | |
| For Use With | |
| Fuse Size | |
| Fuse Type | |
| Fuseholder Type | |
| Lead Style | |
| Mounting Type | |
| Number of Circuits | |
| Orientation | |
| Termination Style | |
| Voltage | |
| Voltage Rating (Maximum @ 125 VAC) | |
| Voltage Rating (Maximum @ 250 VAC) |
The OptiFuse BLC-20C is a single-pole fuse block designed for 5x20mm cartridge fuses. It is rated for 8A at both 125VAC and 250VAC. The block is chassis mounted using screws and features quick connect terminals of 0.187" (4.7mm). The body is made of PBT with a UL 94V-0 flammability rating, and the contacts are nickel-plated brass. Multiple blocks can be snapped together for multi-pole applications. The fuse block is compatible with 2AG, 5mm x 15mm, and 5mm x 20mm fuse sizes. Orientation is horizontal and vertical. These specifications are derived from the manufacturer's datasheet.
The BLC-20C is rated for 8A at both 125VAC and 250VAC.
It is rated for 125VAC and 250VAC maximum.
It accepts 2AG, 5mm x 15mm, and 5mm x 20mm cartridge fuses.
It is chassis mounted by screws.
Termination is via quick connect 0.187" (4.7mm).
Body is PBT with UL 94V-0 flammability rating.
Yes, single fuse blocks can be snapped together for multi-pole applications.
