The Inventus Power BFS500-24 is an open-frame AC/DC converter designed for commercial ITE applications. It delivers a regulated 24VDC output with a maximum current of 20A, providing a total power of 500W.
This converter operates with an input voltage range of 105/115/125 VAC and a frequency of 47-400 Hz. It features fully isolated output with 1500 VAC input/output isolation. The operating temperature range is from 0°C to 40°C, with a storage temperature range of -55°C to 85°C.
Mechanical specifications include dimensions of 9.0 x 4.6 x 5.6 inches and a weight of 20 lbs. The BFS500-24 is designed for chassis mounting and utilizes transformer lugs for input connections. It meets FCC class B and CISPR 22 class B EMI standards.
The BFS500-24 provides an unregulated 24 VDC output with a tolerance of +/-10% at full load.
The BFS500-24 has a maximum output current of 20 A at full load.
The operating temperature range for the BFS500-24 is 0°C to 40°C.
The dimensions of the BFS500-24 are 9.0 x 4.6 x 5.6 inches.
The BFS500-24 supports chassis mounting.
