| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
11 pcs
|
11 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Length - Mating | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Style | |
| Lead-Free Solderable | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Overall Contact Length | |
| Packaging Type | |
| Pitch | |
| Prop 65 | |
| Row Spacing | |
| Shrouding | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination |
The Samtec BDL-107-T-F is a 14-position, 2-row header from the BDL series of low profile double row screw machine terminal strips. It features male pins with tin plating, a 2.54mm pitch, and through hole mounting for secure PCB attachment. The unshrouded design with push-pull fastening allows easy mating and unmating with compatible socket strips such as the SD, SDL, SS, and SL series.
Key specifications include an insulation height of 2.15mm, overall contact length of 8.43mm, and a mating contact length of 3.10mm. The insulator is made of black glass filled polyester, and the operating temperature range spans -55°C to 125°C. The connector is lead-free solderable and designed for board-to-board stacking applications.
Packaging is in tubes with a standard quantity of 32 pieces per tube. The part is RoHS compliant and carries a California Proposition 65 warning for nickel and lead. No current or voltage ratings are specified in the available data.
It has 14 positions arranged in 2 rows.
The pitch is 2.54mm (0.100").
Through hole mounting.
-55°C to 125°C.
Tin plating.
Yes, it is listed as RoHS3 compliant.
Packaged in tubes with 32 parts per tube.
