The BD7F100HFN-EVK-002 is a fully populated evaluation board from ROHM Semiconductor designed for the BD7F100 isolated flyback DC/DC step-down converter IC. It delivers a single isolated output of 24V at 1A, switching at a fixed frequency of 400kHz. The board is ready-to-use and includes populated board(s) for immediate testing.
The flyback topology provides galvanic isolation between input and output, making it suitable for applications requiring isolation. The board is intended for evaluating the BD7F100 IC in step-down configurations, allowing engineers to verify performance, efficiency, and thermal behavior before integrating into a final design.
| Qty | Low | High |
|---|---|---|
| 1+ | $157.50 | $157.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
DC/DC step-down conversion with isolated output.
Flyback topology.
24V output at 1A.
400kHz.
BD7F100.
Fully populated.
The RoHS status is reported as RoHS3 compliant but is unverified.
