| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
28,299 pcs
|
28299 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
12,000 pcs
|
12000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
5,245 pcs
|
5245 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | |
| Junction Temperature | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Storage Temperature | |
| Supplier Device Package | |
| Transistor Type | |
| Vce Saturation (Max) @ Ib, Ic | |
| Voltage |
The BD138 is a PNP epitaxial silicon transistor from STMicroelectronics, part of the BD136 series. It is designed for medium power amplification and switching applications. Key electrical characteristics include a maximum collector-emitter voltage (VCEO) of -60V, collector-base voltage (VCBO) of -80V, and a continuous collector current (IC) of -1.5A (pulse up to -3.0A). The DC current gain (hFE) ranges from 40 to 250 depending on the suffix, with a minimum of 40 at 150mA and 2V. The collector-emitter saturation voltage (VCE(sat)) is typically -0.5V at 500mA. Power dissipation is 12.5W at case temperature 25°C and 1.25W at ambient 25°C. The device is housed in a through-hole SOT32-3 package (TO-225AA / TO-126-3) and is Pb-Free. It operates over a junction temperature range up to 150°C and can be stored from -55°C to 150°C. The BD138 is the complement to the NPN BD135 transistor, making it suitable for push-pull and complementary circuit designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.71 | $1.71 |
| 50+ | $0.81 | $0.81 |
| 100+ | $0.73 | $0.73 |
| 500+ | $0.57 | $0.57 |
| 1,000+ | $0.52 | $0.52 |
| 2,000+ | $0.48 | $0.48 |
| 5,000+ | $0.43 | $0.43 |
| 10,000+ | $0.41 | $0.41 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Maximum junction temperature is 150°C, storage temperature range -55 to 150°C.
The datasheet states it is Pb-Free, but RoHS compliance is unverified.
Through-hole package TO-225AA / TO-126-3, also known as SOT-32-3.
-60V.
-1.5A DC, -3.0A pulse.
Minimum 40 at 150mA, 2V; range 63-160 for BD13810 suffix, 100-250 for BD13816 suffix.
12.5W at case temperature 25°C, 1.25W at ambient 25°C.
