| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,480 pcs
|
1480 pcs | On Request | 1 | On Request | On Request | 07+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Active Area | |
| Current | |
| Dimensions | |
| Mounting Type | |
| Operating Temperature | |
| Spectral Range | |
| Viewing Angle | |
| Voltage | |
| Wavelength | |
| Weight |
The TDK Corporation BCS5030G1 is a photodiode designed for optical sensing applications. It exhibits a peak sensitivity at 580nm, with a spectral sensitivity area spanning from 350nm to 750nm, closely matching human eye visibility.
This device operates within a temperature range of -20°C to 85°C and has a maximum voltage rating of 6V. The photodiode is available in a 2012 (5030 Metric) package and is designed for surface mounting.
Key electrical characteristics include a typical output current of 0.10 μA at 100Lux and VR=0V, and a dark current of 10 pA at VR=0.05V. The component is also noted as being lead-free and cadmium-free.
Applications for this photodiode include brightness control for LCDs, keypads, and exposure adjustments in cameras, where accurate light measurement is crucial.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.50 | $1.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The peak sensitivity wavelength of the BCS5030G1 photodiode is 580nm.
The spectral sensitivity area for the BCS5030G1 photodiode ranges from 350nm to 750nm.
The BCS5030G1 photodiode can operate at temperatures up to 85°C.
The BCS5030G1 photodiode has a maximum voltage rating of 6V.
The BCS5030G1 photodiode is available in a 2012 (5030 Metric) package and a Radial package.
The BCS5030G1 photodiode supports both Surface Mount and Through Hole mounting types.
The dark current for the BCS5030G1 photodiode is a maximum of 10 pA at VR=0.05V, or a maximum of 30nA at VR=5V.
