| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,472 pcs
|
1472 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Data Rate | |
| Frequency | |
| GPIO | |
| Interface | |
| Modulation | |
| Mounting Type |
The BCM43907KWBGT from Infineon is a versatile RF Transceiver integrated with a microcontroller, designed for wireless communication applications. It supports the WiFi 802.11b/g/n standards, enabling robust connectivity.
This component operates in both the 2.4GHz to 2.5GHz and 4.9GHz to 5.845GHz frequency bands, offering flexibility for various deployment scenarios. It achieves a maximum data rate of 150Mbps and features a transmit power of 20.5dBm, along with a receive sensitivity of -98.9dBm.
Onboard memory includes 640kB of ROM and 2MB of SRAM, supported by a range of interfaces such as I2C, I2S, JTAG, SPI, and UART. It also provides 17 GPIO pins for system integration. The device operates within a voltage range of 1.71V to 3.63V and has an operating temperature range of -30°C to 85°C.
The BCM43907KWBGT is supplied in a compact 316-WLCSP package measuring 4.91x5.85mm, designed for surface mounting.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.71 | $0.71 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It supports WiFi 802.11b/g/n standards.
It operates in the 2.4GHz to 2.5GHz and 4.9GHz to 5.845GHz frequency bands.
The maximum data rate is 150Mbps.
The transmit power is 20.5dBm.
The receive sensitivity is -98.9dBm.
It has 640kB of ROM and 2MB of SRAM.
Available interfaces include I2C, I2S, JTAG, SPI, and UART.
The operating voltage range is 1.71V to 3.63V.
The operating temperature range is -30°C to 85°C.
It is supplied in a 316-WLCSP package with dimensions of 4.91x5.85mm.
