| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
960 pcs
|
960 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | |
| Frequency | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Supplier Device Package | |
| Tape & Reel | |
| Transistor Type | |
| Vce Saturation (Max) @ Ib, Ic | |
| Voltage |
The BC817DPN-TP is a bipolar transistor array from Micro Commercial Components, combining an NPN and a PNP transistor in a single SOT-23-6 surface mount package. This device is designed for general-purpose switching and amplification applications where space is limited.
Key electrical characteristics include a minimum collector-emitter breakdown voltage of 45V, a maximum power dissipation of 370mW, and a DC current gain (hFE) of 160 minimum at 100mA collector current and 1V collector-emitter voltage. The NPN transistor has a typical transition frequency of 100MHz, while the PNP transistor has 80MHz. The maximum collector-emitter saturation voltage is 700mV at 50mA base current and 500mA collector current.
The device is housed in a SOT-23-6L package (supplier device package) and operates over a junction temperature range of -55°C to 150°C. It is RoHS3 compliant and has an MSL of 1 (unlimited). The surface mount package makes it suitable for automated assembly in compact electronic designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.51 | $0.51 |
| 10+ | $0.35 | $0.35 |
| 100+ | $0.22 | $0.22 |
| 500+ | $0.14 | $0.14 |
| 1,000+ | $0.12 | $0.12 |
| 3,000+ | $0.12 | $0.12 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
45V minimum.
SOT-23-6 surface mount package.
-55°C to 150°C (junction temperature).
Yes, RoHS3 compliant (unverified).
Minimum 160 at 100mA collector current and 1V Vce.
Maximum 700mV at 50mA base current and 500mA collector current.
NPN: 100MHz typical, PNP: 80MHz typical.
