BC817-25W-TP BC817-25W-TP is an NPN bipolar junction transistor from Micro Commercial. It features a maximum collector-emitter voltage of 45V, collector current of 500mA, and DC current gain of 160-400.
Mfr Part #:

BC817-25W-TP

Available from 1 distributors
Mfr Name: Micro Commercial
Micro Commercial
BC817-25W-TP is an NPN bipolar junction transistor from Micro Commercial. It features a maximum collector-emitter voltage of 45V, collector current of 500mA, and DC current gain of 160-400.
✓ Total Stock: 445,885 pcs
$ Price Range: $0.04

BC817-25W-TP Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
445,885 pcs
On Request
445885 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

BC817-25W-TP Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
DC Current Gain (hFE) (Min) @ Ic, Vce
Frequency
Halogen Free
Mounting Type
Operating Temperature
Power
SVHC Present
Storage Temperature
Supplier Device Package
Tape & Reel
Transistor Type
Vce Saturation (Max) @ Ib, Ic
Voltage
View Similar Products (0)

BC817-25W-TP Description

Short technical summary and product information.

The BC817-25W-TP is an NPN bipolar junction transistor from Micro Commercial, rated for a maximum collector-emitter voltage of 45V, collector current of 500mA, and power dissipation of 200mW. The DC current gain (hFE) ranges from 160 to 400 at 100mA collector current. The transistor is surface mount packaged in SOT-323 (SC-70) case. It is RoHS compliant and halogen free, with a moisture sensitivity level of 1. The operating junction temperature range is -55°C to 150°C. The device features a maximum saturation voltage of 700mV at 500mA, and a typical transition frequency of 100MHz.

BC817-25W-TP Quick Information

Product Type: Bipolar Junction Transistor (BJT)
Canonical Name: BC817-25W-TP NPN Bipolar Junction Transistor
Subcategory: Single BJT

BC817-25W-TP Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Moisture Sensitivity Level 1 - Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

BC817-25W-TP Estimated Pricing

Qty Low High
3,000+ $0.04 $0.04

Estimated market price range - modelled values for guidance only, not live distributor offers.

BC817-25W-TP Features

  • NPN bipolar transistor with 45V collector-emitter voltage.
  • DC current gain range of 160 to 400.
  • Surface mount SOT-323 package for compact design.
  • 100MHz transition frequency for switching circuits.
  • RoHS compliant and halogen free finish.

BC817-25W-TP Applications

  • General purpose switching and amplification circuits.
  • Low to medium power driver stages.
  • Consumer and industrial electronic modules.

BC817-25W-TP FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum collector-emitter voltage (VCEO) of BC817-25W-TP?

45V.

What is the package type for BC817-25W-TP?

SC-70, SOT-323 (surface mount).

What is the operating temperature range?

-55°C to 150°C (junction temperature).

Is the BC817-25W-TP RoHS compliant?

Yes, it is RoHS3 compliant.

What is the DC current gain (hFE) range?

160 to 400 at Ic=100mA, Vce=1V.

What is the maximum collector current?

500mA.

What is the transition frequency?

100MHz typical.
