| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
67 pcs
|
67 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Contact_Retention_Force | |
| Current Rating (Amps) | |
| Durability | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Low Level Circuit Resistance | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The GCT BC034-08-A-V-0150-L-C is an 8-position single row unshrouded header connector designed for board-to-board interconnections. It features a 1.00mm pitch, male pins, and a surface mount right angle orientation with solder termination. The contacts are made of phosphor bronze with a gold flash finish, housed in a black liquid crystal polymer (LCP) insulator rated UL94 V-0 for flammability.
Electrical ratings include 1A per contact current capacity and 250VAC/DC voltage rating. The connector offers low level circuit resistance of 20 mΩ initially and 30 mΩ after environmental testing. Contact retention force is a minimum of 1.0N per pin, and the connector is rated for 100 mating cycles.
This component operates over a temperature range of -40°C to 105°C, making it suitable for a wide variety of environments. The push-pull fastening type allows easy mating and unmating. The unshrouded design provides flexibility in board stacking and space-constrained layouts.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.79 | $1.79 |
| 10+ | $1.52 | $1.52 |
| 100+ | $1.29 | $1.29 |
| 500+ | $1.15 | $1.15 |
| 1,000+ | $1.10 | $1.10 |
| 2,500+ | $1.03 | $1.03 |
| 5,000+ | $0.98 | $0.98 |
| 7,500+ | $0.95 | $0.95 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
8 positions.
1.00mm.
1A per contact.
250VAC/DC.
Surface mount, right angle.
-40°C to 105°C.
Gold flash.
