| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9,615 pcs
|
9615 pcs | On Request | 1 | On Request | On Request | 537 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| California Proposition 65 | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Minimum Order Quantity | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Packaging Type | |
| Pitch | |
| SVHC Present | |
| Shrouding | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination |
The Samtec BBL-107-G-E is a low profile single row screw machine terminal strip from the BBL series. It is a 7-position unshrouded header with male pins arranged in a single row at 2.54mm (0.100") pitch. The connector uses through hole mounting with solder termination and push-pull fastening. The insulation is black liquid crystal polymer (LCP) with an insulation height of 1.78mm. Contacts are circular male pins with nickel finish (20.0µin thickness) and a contact length of 2.67mm. The overall contact length is 7.62mm. Operating temperature range is -55°C to 125°C. This connector is suitable for board-to-board applications. Packaging is in tubes with 32 pieces per tube. Compliance includes RoHS3, REACH (contains lead), halogen free, and MSL level 1. Note: California Proposition 65 warning for nickel and lead content.
7 positions.
2.54mm (0.100").
Through hole.
Nickel with 20.0µin thickness.
-55°C to 125°C.
Yes, RoHS3 compliant per manufacturer.
Tube packaging with 32 pieces per tube.
